GCC-10212 Ultraviolet Aluminum Mirrors

Two UV aluminum mirror options are distinguished by complete model and the diameter-symbol value printed on each card: φ50.8 for GCC-102125 and φ25.4 for GCC-102122. The source supplies neither length units, individual dimensioned drawings nor optical performance tables. These descriptions retain the UV aluminum designation, model identity and original values while flagging units, mounting, substrate and reflectance data for confirmation. The shared photograph of two optics is not evidence of model-specific color, scale or pack quantity.

Models and size notation

The GCC-102125 card says UV aluminum mirror φ50.8; GCC-102122 says φ25.4. The diameter symbol and values are retained without adding mm, because no unit is printed. Thickness, diameter tolerance, clear aperture and dimensional reference are absent. Model digits are not decoded, and sizes from other mirror families are not assigned.

UV aluminum designation and optical data

UV aluminum mirror is an explicit source designation. The aluminum reflective-coating category is retained without treating the entire body as aluminum. UV band limits, reflectance spectrum, reflectance, incidence angle and polarization are unspecified. The name alone does not establish broadband coverage, efficiency at a particular wavelength or high-power suitability. Protective layer, substrate, surface figure and surface quality also require confirmation.

Appearance and mounting

Both options reuse a photograph of two unmounted circular optics with blue or pale-gray faces and substantial pale edges. Color does not identify individual models or coating performance; two displayed pieces do not establish a two-piece pack. Rear construction, mechanical interfaces, clamping requirements and holder information are absent. The edge is not evidence of an included mounting ring.

Custom sizes and supply

The source offers custom sizes without a separate custom SKU. Only the two listed standard options are retained; other sizes are not added. Damage threshold, power, temperature, cleaning procedure and accessories are unknown. The source lists 2–7 days for dispatch. Confirm current lead time, quantity and supply scope separately.

Selection checklist

Complete model and units for the φ value

Diameter tolerance, thickness and clear aperture

Actual band, incidence angle and reflectance spectrum

Substrate, clamping, quantity and delivery

To be confirmed

Dimension units, thickness, tolerances and clear aperture

Substrate, protective layer and rear construction

Band limits, reflectance, incidence angle and polarization

Surface figure, surface quality, damage threshold and supply quantity
