GCCH-1013 Ultraviolet Laser-Line Mirrors

Three UV single-wavelength mirror options are distinguished by their stated wavelength: 248, 308 or 351 nm. Each source card provides a corresponding percentage claim but no measurement conditions or individual dimensioned drawing. These descriptions preserve complete model identity, explicit wavelength and source reflectance wording while separating the undefined number 25 from confirmed specifications. Mounting, material and power data remain open items rather than being inferred from promotional artwork.

Models and wavelengths

The three complete models are GCCH-101302, GCCH-101322 and GCCH-101332, with card wavelengths of 248, 308 and 351 nm respectively. Match the full model to the actual operating wavelength; model digits are not decoded into dimensions or coating. The single-wavelength designation does not establish broadband coverage.

Reflectance and an undefined number

The cards state “deep UV 25>99%@248nm”, “deep UV 25>99.5%@308nm” and “deep UV 25>99.5%@351nm”. Percentages are retained as source reflectance claims; incidence angle, polarization and measurement conditions are unspecified. The preceding number 25 has no field name, unit or symbol and is not treated as a verified diameter, angle or clear aperture.

Appearance and mounting

Cards reuse photographs of two unmounted circular optics with substantial pale edges and pale blue or gray faces. Appearance does not establish substrate composition, coating layers or this model’s dimensions, and two photographed pieces do not establish pack quantity. Obtain individual drawings for diameter, thickness, tolerances, clear aperture, rear construction and clamping requirements. No holder is shown as an included accessory.

Operating data and custom sizes

The cards offer custom sizes but provide no separate custom SKU or standard dimension table. Reflectance spectra, wavelength tolerance, surface figure, surface quality, damage threshold, temperature and cleaning procedures are absent; laser-power ratings and certifications are not invented. The source lists 2–7 days for dispatch. Confirm current lead time, quantity and accessories.

Selection checklist

Complete model and operating wavelength

Reflectance measurement angle and polarization

Original definition of 25 and dimensioned drawing

Mounting, power, quantity and current delivery

To be confirmed

Meaning and unit of 25

All dimensions, clear aperture and material

Incidence angle, polarization, reflectance spectrum and wavelength tolerance

Surface figure, surface quality, damage threshold and quantity
