GCCH-1041 Broadband Laser Mirrors for 0–45° AOI

Eight broadband laser mirrors are distinguished by complete model, diameter with explicit mm units and source band, covering four bands in two diameter options each. The series heading states0–45° incidence, and individual cards give Rave>99% for their band. These descriptions retain the average-reflectance claim without expanding it into a minimum at every wavelength or angle. Missing mechanical dimensions, measurement conditions, materials and laser damage data are listed separately. Artwork supports family appearance only.

Models, diameters and bands

The 350–400 nm pair is GCCH-104103/104105; 400–700 nm is104113/104115; 700–1100 nm is104123/104125; and1100–1600 nm is104133/104135. Diameters within each pair are25.4/50.8 mm respectively, with explicit φ and mm on the cards. Model digits are not used to derive additional parameters. Thickness, tolerances and clear aperture are absent.

Average reflectance and incidence angle

Every card states Rave>99% for its band. This is retained as an average-reflectance claim, not a minimum at every wavelength. The series heading explicitly states0–45° incidence, but averaging method, polarization, angle-resolved curves and measurement conditions are absent. More than99% at every wavelength and angle is not guaranteed. The source word new is not a verified release date or upgrade comparison.

Appearance and mechanical mounting

Cards reuse a photograph of several blue circular optics with pale and dark edges. Color does not identify models or bands, and photographs do not establish scale, exact thickness or coating material. Multiple displayed pieces do not establish a kit quantity. Obtain individual mechanical drawings for rear construction, clamping, holders and clear aperture. Other families’ coatings are not assigned.

Laser conditions and supply

Power, damage threshold, pulse duration, surface figure, surface quality, substrate, temperature and cleaning procedure are absent. The laser designation does not establish high-power compatibility. Custom sizes are offered without a separate custom SKU. The source lists2–7 days for dispatch; confirm current delivery, quantity and accessories.

Selection checklist

Complete model, diameter and band

Averaging method, polarization and angle-resolved spectra

Thickness, tolerance, clear aperture and mechanical drawing

Material, power, quantity and delivery

To be confirmed

Average definition, test conditions and polarization

Angle-resolved wavelength curves and minimum reflectance

Thickness, tolerances, clear aperture, substrate and coating

Surface figure, damage threshold, pulse conditions and supply quantity
