GCCH Laser Mirrors

Four mirror options in this source are explicitly labeled argon-ion and distinguished by complete model and card band, each with a>98% claim. The naming difference between the1011 heading and actual1014 models is preserved rather than silently corrected. Explicit nm bands are recorded, while the undefined number25, reflectance test conditions, dimensions and laser handling limits are listed for confirmation. Shared photographic color and broad promotional naming are not used to invent engineering specifications.

Models and naming difference

The cards identify GCCH-101422 at458–528 nm, GCCH-101412 at351–364 nm, GCCH-101402 at300–308 nm and GCCH-101432 at244–257 nm, each labeled argon-ion. The overall heading says GCCH-1011 broadband laser and argon-ion mirrors, whereas individual models start1014. Both source wordings are preserved without changing model identity or merging other families.

Reflectance and an undefined25

Every card says25 >98% at its band. Percentages are retained as source reflectance claims without an explicit average/minimum definition, incidence angle, polarization, curves or measurement conditions. The number25 has no unit, φ symbol or field name and is not a verified diameter. Another mirror’s25.4 mm size or angle condition is not assigned.

Appearance and mechanical data

Cards share a photograph of three circular optics with gray or pale-blue faces and pinkish or pale edges. Color does not identify an individual model, band or substrate. Three displayed pieces do not establish a three-piece pack. Diameter, thickness, tolerances, clear aperture, rear construction, clamping and holder compatibility are absent; obtain individual model drawings.

Laser conditions and custom sizes

Argon-ion and broadband are source designations, not compatibility with every argon-ion line, arbitrary power or pulse condition. Coating structure, substrate, surface figure, surface quality, damage threshold, power, temperature and cleaning requirements are absent. Custom sizes are offered without a separate custom SKU. The source lists2–7 days for dispatch; confirm current delivery, quantity and accessories.

Selection checklist

Complete model, band and source naming difference

Definition of25, incidence angle and polarization

Reflectance definition, curves and test conditions

Dimensioned drawing, power, quantity and delivery

To be confirmed

Meaning/unit of25 and all dimensions

Average/minimum reflectance definition, incidence angle and polarization

Substrate, coating, surface figure and damage threshold

Mounting, temperature, cleaning and quantity
