GCL-0711 Wollaston Prisms

The source lists GCL-071111, GCL-071113 and GCL-071110 in the GCL-0711 Wollaston prism series. Individual cards distinguish them by aperture and a two-value outer-dimension field. Apertures are markedφ10,φ15 andφ8 respectively, while the field labeled outer diameter gives25.4 × 19,30 × 23 and25.4 × 17. Neither units nor a definition for the second value are provided. These descriptions retain the original markings and separate housing appearance from unconfirmed engineering dimensions. English artwork supports family identification without establishing beam-separation angle, crystal material, calibrated polarization axes or pack quantity. Obtain optical and mechanical documentation for the complete selected model before assessing system fit and operating suitability.

Models and original dimension fields

The GCL-071111 card gives apertureφ10 and an outer-diameter field of25.4 × 19; GCL-071113 gives apertureφ15 and30 × 23; GCL-071110 gives apertureφ8 and25.4 × 17. No dimension units are stated. The source calls the two-value field outer diameter without defining its second value as length or height. Original wording is retained rather than supplying millimeters or a verified diameter-by-length engineering definition.

Category and optical performance

The source explicitly identifies Wollaston prisms. Crystal material, cemented or contacted construction, operating band, beam-separation angle, transmission, extinction ratio, polarization directions and incidence conditions are absent. The category name is not used to supply numerical performance or an all-wavelength guarantee. Obtain model-specific spectral, separation and axis data.

Housing and face markings

All three models reuse photography showing two short black cylindrical housings with central optical windows and visible internal faces. White lines or grooves on either side are appearance details rather than evidence of calibrated axes. Two displayed units do not establish a two-piece pack or individual model proportions. Confirm housing material, thickness, aperture tolerances, mounting interfaces, clamping regions and accessories.

Selection, custom sizes and delivery

Confirm complete model, aperture unit, outer-dimension field definitions and optical operating conditions before assessing system fit. The source offers custom sizes without establishing unlisted stocked SKUs. Power limits, damage conditions, temperature, cleaning method and pack quantity are unspecified. The source lists2–7 days for dispatch; check current stock, custom-size feasibility and actual delivery with the supplier.

Selection checklist

Complete model,aperture and original outer-diameter field

All units,second outer-value definition and mounting drawing

Operating band,beam-separation angle,extinction ratio and axes

Power conditions,accessories,quantity and delivery

To be confirmed

Dimension units,second outer-value definition and tolerances

Crystal material,joining construction,band and separation angle

Transmission,extinction ratio,incidence,polarization axes and damage limits

Housing material,interfaces,accessories,cleaning and delivery
