XINDA-OM-PS-005
ZGH-38 Ø38 mm Stainless Steel Optical Extension Posts
M6 taps at both ends, a 6 mm transverse torque hole, and 28 source-mapped lengths
- Source-labeled 38 mm precision-ground stainless-steel body
- M6 tapped mounting hole at each end
- 6 mm transverse hole for assembly leverage
- Available models
- 28 standard models
- Lead time
- Confirmed after model and quantity review
- Purchase method
- RFQ by model
Reference price
$58.53 - $535.17
Select a model to view availability.
Not sure which model? Get selection helpProduct overview and selection guidance
Product-family scope, interfaces, selection limits, and supply notes.
ZGH-38 cylindrical stainless steel optical posts have a 38 mm diameter. Series information identifies an M6 tapped hole at each end and a 6 mm transverse through-hole. All 28 individual model photographs explicitly label body length, covering whole-millimeter options from 25 to 1000 mm and inch-based lengths from 25.4 to 355.6 mm. Length naming does not change the 38 mm series diameter.
Length selection
Whole-millimeter models include 25, 30, 50, 75, 100, 125, 150, 200, 250, 300, 350, 400, 450, 500, 600, 750 and 1000. Individual cards for models 1, 1.5, 2, 3, 4, 5, 6, 8, 10, 12 and 14 label 25.4, 38.1, 50.8, 76.2, 101.6, 127, 152.4, 203.2, 254, 304.8 and 355.6 mm respectively. Use the complete model and stated length rather than guessing units.
End interfaces and tool hole
The series feature image identifies M6 tapped holes at both ends; the application image labels a 6 mm transverse through-hole. Individual photographs show axial and transverse openings without model-specific pitch, hole depth or end-face-to-hole-center dimensions. Do not scale photographs or transfer hole positions from another post series. Supplied studs, tools and accessory quantities are unconfirmed.
Mounting and fit
Check the 38 mm holder or clamp fit, useful engagement, overhang and component center of gravity. Do not assume 38 mm and 38.1 mm parts interchange. Longer posts also require space and support checks. Load capacity, tightening torque and clamping force are not supplied; diameter and length do not establish a performance rating.
Material and supply
The source advertises precision-ground stainless steel without grade, roughness, tolerances or a straightness report. Some original color options carry pale-gray or white names alongside explicit models; photographs show silver metal and do not establish coating colors. Series presentation does not define a kit. Holders, bases and optical components are not included automatically.
Selection checklist
Complete model and millimeter length
38 mm clamp fit
M6 threads and hole position
Engagement and support conditions
Quantity and supplied components
To be confirmed
Thread pitch, depth and tool-hole position
Material grade, tolerances and roughness
Loading, straightness and torque
Supplied studs and color-option meaning
Procurement and technical information
Select a model so we can confirm pricing, availability, lead time, and required documents.
Procurement method
Formal RFQ by model
Lead time
Confirmed after model and quantity review
Technical documents
Request drawings and specifications with your RFQ
Typical applications
- Fixed-height support for large optical mounts and assemblies
- Beam-height extension and stacked support structures
- Laboratory benches, inspection fixtures, and teaching systems
- Custom-length 38 mm support-post RFQs
Product highlights
- Source-labeled 38 mm precision-ground stainless-steel body
- M6 tapped mounting hole at each end
- 6 mm transverse hole for assembly leverage
- Metric and inch-designated choices spanning 25–1000 mm and 25.4–355.6 mm
